• Energy efficiency with Grundfos pump
• Reliable performance with quality components and engineering
• Individual project evaluation per request
• ISO 9001 certified factory
• CE marked and confirmed to be safe in accordance with EC New Approach Directives

Equipment

• Grundfos® CR 45-4-2 high-pressure pump — 1 pc
• 8040-6 membrane vessels — 6 pcs
• Stainless steel housing with 7 PP 2,5 × 40″ filter — 2 pcs
• Motorized feed water in, flush out butterfly valves — 2 pcs
• Balancing concentrate reject, concentrate recycle valves — 2 pcs
• Electrical cabinet with Ecosoft controller — 1 set
• Piping, instrumentation — 1 set
• Steel frame — 1 set

Options

• Filmtec™ XLE-440 / ECO PRO-440 or Ecosoft ELP-8040 membranes
• Dosing pump for antiscalant or other RO chemicals
• Permeate inlet for permeate membrane rinse
• Raw water blending line

Сonnections

• Influent water — DN100 (flange)
• Permeate — DN80 (flange)
• Concentrate — DN100 (flange)
• CIP inlet — DN80 (flange)
• CIP return — DN80 (flange)

Technical data

• Permeate capacity¹ — 36 m³/h
• Permeate recovery² — 75%
• Maximum TDS — 3000 mg/L
• Influent flow demand — 50…60 m³/h (service)
• Operating pressure — 8…12 bar
• Maximum pressure — 14 bar
• Electrical requirements — 380...400 V, 50 Hz (3 ph)
• Electrical power — 22 kW
• Prefilter rating — 5 μm
  ¹ depends on feed water TDS, temperature, and permeate recovery
  ² for low scaling/fouling water

Feed water requirements

• TDS — 3000 mg/L
• hardness — 150 mg/L CaCO₃
• iron — 0.1 mg/L
• manganese — 0.05 mg/L
• hydrogen sulfide — none
• silicate — 20 mg/L
• residual chlorine — 0.1 mg/L
• SDI — 5
• chemical oxygen demand - 4 mg/L O₂
